PRODUCTS

SFF

2.5 Gb/s 1-fiber

1 / 1

2X5 SFF WDM MM

Product Number	Bit Rate	Reach	TX	RX	Voltage	Package	Temperature Range	TX Power	RX Sens.	Data Sheet
BTRS-9600MG	2.5 Gb/s	300 m	1310 nm	1550 nm	3.3 V	2x5 SC	0 ~ 70°C	0 to -10 dBm	-16 dBm
BTRS-9600AMG	2.5 Gb/s	300 m	1310 nm	1550 nm	3.3 V	2x5 SC	-40 ~ 85°C	0 to -10 dBm	-16 dBm
BTRS-9700MG	2.5 Gb/s	300 m	1550 nm	1310 nm	3.3 V	2x5 SC	0 ~ 70°C	0 to -10 dBm	-16 dBm
BTRS-9700AMG	2.5 Gb/s	300 m	1550 nm	1310 nm	3.3 V	2x5 SC	-40 ~ 85°C	0 to -10 dBm	-16 dBm

2X5 SFF WDM SM

Product Number	Bit Rate	Reach	TX	RX	Voltage	Package	Temperature Range	TX Power	RX Sens.	Data Sheet
BTRS-9605G	2.5Gb/s	5 km	1310 nm	1550nm	3.3 V	2x5 SC	0 ~ 70°C	-3 to -9dBm	-18dBm
BTRS-9605AG	2.5Gb/s	5 km	1310 nm	1550nm	3.3 V	2x5 SC	-40 ~ 85°C	-3 to -9dBm	-18dBm
BTRS-9705G	2.5Gb/s	5 km	1550 nm DFB	1310nm	3.3 V	2x5 SC	0 ~ 70°C	-3 to -9dBm	-18dBm
BTRS-9705AG	2.5Gb/s	5 km	1550 nm DFB	1310nm	3.3 V	2x5 SC	-40 ~ 85°C	-3 to -9dBm	-18dBm
BTRS-9620G	2.5Gb/s	20 km	1310 nm DFB	1550 nm	3.3 V	2x5 SC	0 ~ 70°C	0 to -5 dBm	-18 dBm
BTRS-9620AG	2.5Gb/s	20 km	1310 nm DFB	1550 nm	3.3 V	2x5 SC	-40 ~ 85°C	0 to -5 dBm	-18 dBm
BTRS-9720G	2.5Gb/s	20 km	1550 nm DFB	1310 nm	3.3 V	2x5 SC	0 ~ 70°C	0 to -5 dBm	-18 dBm
BTRS-9720AG	2.5Gb/s	20 km	1550 nm DFB	1310 nm	3.3 V	2x5 SC	-40 ~ 85°C	0 to -5 dBm	-18 dBm
BTRS-9640G	2.5Gb/s	40 km	1310 nm DFB	1550 nm	3.3 V	2x5 SC	0 ~ 70°C	4 to 0 dBm	-20 dBm
BTRS-9640AG	2.5Gb/s	40 km	1310 nm DFB	1550 nm	3.3 V	2x5 SC	-40 ~ 85°C	4 to 0 dBm	-20 dBm
BTRS-9740G	2.5Gb/s	40 km	1550 nm DFB	1310 nm	3.3 V	2x5 SC	0 ~ 70°C	3 to -2 dBm	-20 dBm
BTRS-9740AG	2.5Gb/s	40 km	1550 nm DFB	1310 nm	3.3 V	2x5 SC	-40 ~ 85°C	3 to -2 dBm	-20 dBm
BTRS-9780-1510G	2.5Gb/s	80 km	1510 nm DFB	1590 nm	3.3 V	2x5 SC	0 ~ 70°C	3 to -2 dBm	-28 dBm
BTRS-9780A-1510G	2.5Gb/s	80 km	1510 nm DFB	1590 nm	3.3 V	2x5 SC	-40 ~ 85°C	3 to -2 dBm	-28 dBm
BTRS-9780-1590G	2.5Gb/s	80 km	1590 nm DFB	1510 nm	3.3 V	2x5 SC	0 ~ 70°C	3 to -2 dBm	-28 dBm
BTRS-9780A-1590G	2.5Gb/s	80 km	1590 nm DFB	1510 nm	3.3 V	2x5 SC	-40 ~ 85°C	3 to -2 dBm	-28 dBm
